MODBUS TCP

MODBUS TCP is a widely used industrial communication standard adapted to operate over Ethernet/TCP-IP networks.

Modbus TCP frame structure

The structure of a Modbus TCP frame can be seen below.

Modbus TCP frame structure
Field	Size	Description
Transaction ID	2 bytes	This field allows pairing of transactions when a client sends multiple messages over the same TCP connection without waiting for prior responses.
Protocol ID	2 bytes	This field is always 0 for Modbus services.
Length	2 bytes	A byte count of the remaining fields including: the unit identifier byte, function code byte, and the data fields.
Unit ID	1 byte	This field is used to identify a remote server located on a non-TCP/IP network.
Function code	1 byte	Defines the register type. See function code table below for details.
Data	N bytes	Contains the requested data (register addresses and values).

Modbus register addressing

Modbus typically organizes data into four register types:

Modbus register addressing
Register type	Address range	Size	Read/write	Purpose
Coils	00001 - 09999	1-bit	Read/Write	Controls binary outputs (e.g., turning devices ON/OFF).
Discrete inputs	10001 - 19999	1-bit	Read-only	Stores binary input signals from e.g. sensors or switches.
Input registers	30001 - 39999	16-bit	Read-only	Stores input data (e.g., sensor readings or status) that the master can only read.
Holding registers	40001 - 49999	16-bit	Read/Write	Stores output or configuration data that the master can read and modify.

Modbus function codes

Modbus function codes
Function code	Description
01	Read coils
02	Read discrete inputs
03	Read holding registers
04	Read input registers
05	Write single coil
06	Write single holding register
15	Write multiple coils
16	Write multiple holding registers

Example

In Modbus communication, you can define the order in which data appears within register addresses. For example, if input registers are selected (see Modbus TCP configuration in network configuration commands for instructions) and you select roll, pitch, and heave as shown in the table below, roll will be stored in registers 30001 and 30002, pitch in 30003 and 30004, and so on. Since each value is stored as a 32-bit IEEE 754 single-precision floating-point number, it occupies two 16-bit Modbus registers.

Register address	Parameter	Data type	Unit	Register value (U16) decimal	Numerical value
30001	roll (MSB)	Single precision float (IEEE 754)	[deg]	16405	2.34
30002	roll (LSB)	Single precision float (IEEE 754)	[deg]	49807	2.34
30003	pitch (MSB)	Single precision float (IEEE 754)	[deg]	49084	-1.47
30004	pitch (LSB)	Single precision float (IEEE 754)	[deg]	10486	-1.47
30005	heave (MSB)	Single precision float (IEEE 754)	[m]	48990	-0.87
30006	heave (LSB)	Single precision float (IEEE 754)	[m]	47186	-0.87

Let's examine how the roll value (2.34 degrees) is retrieved from Modbus registers.

Register address

Parameter

Data type

Unit

Register value (U16) binary

Register value (U16) decimal

Numerical value

30001

roll (MSB)

Single precision float (IEEE 754)

[deg]

01000000 00010101

16405

2.34

30002

roll (LSB)

11000010 10001111

49807

These two 16-bit registers form a 32-bit binary word in big-endian format. When combined in big-endian order, the full 32-bit IEEE 754 floating-point representation is: 01000000 00010101 11000010 10001111.

IEEE 754 single-precision floating-point numbers are structured as follows:

Bit position	Component	Extracted bits
Bit 1	Sign (S)	0 (positive)
Bits 2-9	Exponent (E)	10000000 (decimal: 128)
Bits 10-32	Mantissa (M)	00010101110000101000111

The roll value is computed using the IEEE 754 formula:

Roll value = (-1)^sx 1.M x 2^(E-127) = (-1)⁰ x 1.00010101110000101000111₂ x 2^(128−127) = 1.16796875 x 2¹= 2.3359375.

Due to rounding errors, the final roll angle is 2.34 degrees.

Note

When using several MRUs they must be configured with unique IP addresses to access data from the specified MRU and to avoid IP conflict.
